PRODUCT NAME :
stainless steel
STANDARD:
GB/T1220-2007 GB/T1221-2007 GB/T20878-2007 ASTM A959-04 ISO4955:2005 ISO683-13 ISO683-16 EN10088:1-1995 EN10095-1999
GRADE COMPARISION:
|
GB |
ASTM |
BS |
JIS |
DIN |
|
06Cr13Al |
405 |
X6CrAl13 |
SUS405 |
1.4002 |
ULTRASONIC STANDARD:
GB/T6402-2008 / SEP921-84. ASTM A388
CHEMICAL COMPOSITION:
|
C |
Si |
Mn |
P≤ |
S≤ |
Cr |
Ni |
|
0.08 |
1.00 |
1.00 |
0.040 |
0.030 |
11.5/14.50 |
(0.60) |
HEAT TREATMENT SPECIFICATION & MECHANICAL PROPERTIES:
Tensile strength : σb (MPa)：≥410
Yeild strength σ0.2 (MPa)：≥177
Elongation δ5 (%)：,≥20
Reduction of area ψ (%)：≥60
Impact Akv (J)：≥78
Hardness ≤183HB
Annealing 780-830 rapid cooling .
DELIVERY CONDITION :
DIMENSION : mm
APPLIED RANGE:
APPLIED RANGE:
Used for offshore platform, helicopter deck ,other platform, food industry, pulp and papermaking, aerospace
( turbine motor blade) and nuclear wastebin.
REMARK：
Above listed parameters and sepcification only for reference . Specific parameters according to standard. Requirments
beyond standard will be negotiate by both sides .
Delivery state:annealed, spheroidal annealed, quenched & tempered ,bright bar, cold-drawn, etc.
Listed specifications are only typical grades; products of required specifications can be developed/produced per
international, Chinese or industry standards, or based on agreements with customers.
